If the filter elements become full of debris, the restriction to the flow of oil causes a pressure increase inside the filter. The pressure oil causes bypass valve (6) to move against the force of spring (4). The oil then flows past the open bypass valve to the remainder of the hydraulic system. When the oil does not go through the filter elements, the debris in the oil will cause damage to other components in the hydraulic system. Caterpillar 793D
Correct maintenance must be used to be certain that elements (7) do not become full of debris.
Debris in elements (7) will stop the flow of clean oil to the hydraulic system.

Caterpillar 793D Off-Highway Truck Factory Service Pdf Manual
Caterpillar 793D Off-Highway Truck Factory Service Pdf Manual
Free shipping by email
Price: $39.99

Caterpillar 793D Off-Highway Truck Factory Service Pdf Manual

Torque converter hydraulic filter (1) is fastened to the side of the hydraulic tank. Oil from the torque converter sump goes to the gear pump for the torque converter and the transmission. The torque converter charge pump section sends oil to the torque converter hydraulic filter.
Oil flows through inlet line (2). The oil fills the space between the inside of housing (5), screen
assembly (8), and elements (7). During normal operation, the oil goes through elements (7) and
through outlet line (3). The oil then goes to the torque converter.
