Technical Workshop Guide: Case 9030B Excavator Operator’s Owner Pdf Manual
Need to fix your equipment? This professional service guide is the official resource for expert mechanics. It includes specific electrical wiring diagrams and hydraulic troubleshooting steps tailored for this specific model.
This technical documentation for the Operators Manual series provides OEM specifications, torque settings, and assembly instructions.
- Official Brand Category: VIEW ALL OPERATORS MANUAL MANUALS
- Model Focus: High-resolution data for Case 9030B Excavator Operator’s Owner Pdf Manual.
What's inside this Operators Manual manual?
- Engine Overhaul
- Transmission Specs
- Hydraulic Schematics
- Electrical Diagrams
- Diagnostic Codes
- Maintenance Intervals
CASE 9020b Excavator Operators Pdf Manual DOWNLOAD
Case 9020B Excavator Factory Service Manual
Manual Covers: Case 9030b, 9030b excavator for sale, case 9030b sale, used case 9030b, case 9030b hydraulic excavator
Collection of 2 files – Case 9030B Excavator Service Repair Manual & Operators Owner Instruction Manual – IMPROVED – DOWNLOAD
IMPROVED PDF MANUALS HAVE: Bookmarks, Searchable Text, Index and Improved Quality.
This collection contains the following products:
1- Case 9030B Excavator Service Repair Workshop Pdf Manual
2- Case 9030B Excavator Operators Owner Instruction Pdf Manual
To The Owner Of a Case Machinery
Identification Numbers/ Machine Components
Safety/Decals/Hand Signals
Instruments And Controls
Operating Instructions
Tracks
Lubrication/Maintenance Charts
Lubrication/Filters/Fluids
Maintenance And Lubrication
Electrical System
Specifications
Machine Storage
Index
After Delivery Check
And More……
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
Case 9030B Excavator Operators Owner Pdf Manual
Specification:
ENGINE
Model: Case 6T-590 Type
4-stroke, turbocharged Cylinders
6 Bore/Stroke 4.02” x 4.72”
(102 x 120 mm) Displacement
359 in3 (5.9 L ) Fuel injection
Direct Fuel
Diesel Fuel filter
In-line strainer Air intake
Cross-flow Cooling
Liquid
Horsepower per SAE J1349
Net …. 131 hp (98 kW) @ 2000 rpm
Maximum torque @ 1500 rpm
Net 425 lb·ft (576 N·m)
HYDRAULICS
Pumps (2) Variable displacement axial-piston design
Capacity
Maximum 2 x 51.2 gpm
(194 L/min) Minimum 16 gpm (2 x 61 L/min)
System relief pressure – Standard……. 4554 psi (31 400 kPa)
Power Boost .. 4975 psi (34 300 k Pa)
Control valves –
4-spool section for left track travel,
boom #1, bucket #1 & #2, arm #2 5-spool section for right track
travel, boom #2, auxiliary, swing
and arm #1
Boom and arm holding valves
