The Hitachi Ex60-5 and Ex60LC-5 Operators Manual likely provides concise instructions on the safe and effective operation of your Hitachi excavator models. Here’s a summarized breakdown of the expected key information:

Basic Operation: This section would explain how to start, stop, steer, and maneuver the excavator in a clear and to-the-point manner.

Controls and Instruments: This section would identify the various levers, knobs, pedals, and gauges on the operator’s console and provide a brief explanation of their functions.

Function Overview: It would detail the operation of the excavator’s working functions, likely including:
Boom and arm extension/retraction
Bucket raising/lowering/tilting
Swing control
(For Ex60LC-5) Travel and blade operation (if applicable)

Safety Information: The manual would emphasize important safety precautions throughout, likely including hazard warnings, safe operating procedures, and proper use of personal protective equipment (PPE).

Maintenance Overview: This section might provide a general overview of routine maintenance tasks you can perform, such as checking fluid levels and greasing points.

Read this manual carefully to learn how to operate and service your machine correctly. Failure to do so could result in personal injury or machine damage.

This manual should be considered a permanent part of your machine and should remain with the machine when you sell it.

Hitachi Ex60-5 Operators Manual

Index: Hitachi Ex60-5 Operators Manual
Machine Numbers
Safety
Safety Signs
Components Name
Operator’s Station
Brake-In
Pre-Start Inspection
Operating The Engine,
Driving The Machine,
Operating The Machine,
Transporting,
Maintenance
Storage
Troubleshooting
Specification
Optional Attachments And Devices

Serial Number: 50001 and up
File Format: PDF
Total pages:238
Size: 17Mb
Manual Language: English


Engine
Make Nissan
Model A-BD30
Net Power 54 hp 40.3 kw
Power Measured @ 2200 rpm
Displacement 180.2 cu in 3 L
Torque Measured @ 1500 rpm
Max Torque 133.5 lb ft 181 Nm
Aspiration Natural
Operational
Operating Weight 13889.1 lb 6300 kg
Fuel Capacity 9.4 gal 35.7 L
Cooling System Fluid Capacity 2.6 gal 10 L
Hydrauilc System Fluid Capacity 23.8 gal 90 L
Engine Oil Capacity 3.3 gal 12.5 L
Swing Drive Fluid Capacity 0.48 gal 1.8 L
Operational Voltage 12 V
Alternator Supplied Amperage 25 amps
Hydraulic System Relief Valve Pressure 4550 psi 31371.1 kPa
Hydraulic Pump Flow Capacity 41.8 gal/min 158.4 L/min
Swing Mechanism
Swing Speed 14.5 rpm
Undercarriage
Number of Shoes per Side 37
Shoe Size 17.7 in 450 mm
Number of Carrier Rollers per Side 1
Number of Track Rollers per Side 5
Ground Pressure 4.3 psi 29.4 kPa
Max Travel Speed 3 mph 4.8 km/h
Track Gauge 5.7 ft in 1750 mm
