PowerBox Paver 1639 1649 Operator Manual

PowerBox Paver 1639 1649 Operator Manual

1639/1649
PowerBox
Self Propelled
Paver

Table of Contents:
Chapter Description Page
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Inside Front Cover
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Check Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
5 Controls, Attachments & Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .16
6 Operation & Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
7 Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
8 Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
9 Service & Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
10 Decal Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
11 Maintenance Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Standard Hardware Torque Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
International Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . .Inside Back Cover

PowerBox 1639 1649 Operator Manual
PowerBox 1639 1649 Operator Manual
Free shipping by email
Price: $29.99

PowerBox 1639 1649 Operator Manual The information in this Operator’s Manual was written to give the owner/operator assistance in preparing, adjusting, maintaining, and servicing of the Paver. More importantly, this manual provides an operating plan for safe and proper use of the machine. Major points of safe operation are detailed in the SAFETY chapter of this manual. A chart of standard hardware torques is located in the back of this manual.

The GEHL Company asks that you read and understand the contents of this manual COMPLETELY and become familiar with your new machine, BEFORE attempting to operate it.

PowerBox 1639 1649 Operator Manual Throughout this manual, information is provided which is set in italic type and introduced by the word NOTE. Be sure to read carefully and comply with the message or directive given. Following this information will improve your operating or maintenance efficiency, help you to avoid breakdowns or damage, and extend your machine’s life.

A plastic container is provided on the unit for storing the Operator’s Manual. After using the Manual, please return it to the container and keep it with the unit at all times! If this machine is resold, GEHL Company recommends that this Manual be given to the new owner.

“Right” and “left” are determined from a position standing on the Screed Platform and facing forward.

Our wide Dealership network stands by to provide you with any assistance you may require, including genuine GEHL service parts. All parts should be obtained from or ordered through your GEHL Dealer.

Give complete information about the part and include the model and serial numbers of your machine. Record the serial number in the space provided on the previous page, as a handy record for quick reference.

GEHL Company reserves the right to make changes or improvements in the design or construction of any part without incurring the obligation to install such changes on any unit previously delivered.
